Description
B-23-1 PEDAL (RH)
| Ref No. | Parts No. | Parts Name | Parts Name(S/M) | Unit Qty |
|---|---|---|---|---|
| 1 | 17800-T00-J01 | PEDAL ASSY., ACCELERATOR | Accelerator Pedal Module | 001 |
| 2 | 36750-TY0-J11 | SWITCH ASSY., STOP & CRUISE (TOYO) | Brake Pedal Position Switch | 001 |
| 3 | 36751-T2A-A01 | PIECE, ATTACHING (TOYO) | 002 | |
| 4 | 46510-T8K-E51 | SPRING ASSY., PEDAL RETURN | Return Spring | 001 |
| 5 | 46545-T00-J51 | COVER, PEDAL | Brake Pedal Cover | 001 |
| 6 | 46600-3M0-T51 | PEDAL ASSY., BRAKE | Brake Pedal | 001 |
| 7 | 90104-3M0-J01 | BOLT-WASHER, PAINT CUTTING, 8X36 | 001 | |
| 8 | 90104-SFE-003 | BOLT, FLANGE, 8X23 | 002 | |
| 9 | 90361-S3C-003 | NUT, PAINT CUTTING, 8MM | 002 | |
| 10 | 94050-08080 | NUT, FLANGE, 8MM | 004 |
