Description
B-13-80 SMART UNIT (RH)
| Ref No. | Parts No. | Parts Name | Unit Qty |
|---|---|---|---|
| 1 | 35111-T2A-A51 | KEY COMP., EMERGENCY | 002 |
| 2 | 35118-T2A-A50 | KEY COMP., EMERGENCY (BLANK) | 002 |
| 3 | 38321-T9A-Z00 | BRACKET, SMART POWER CONTROL | 001 |
| 4 | 38329-T9B-Z03 | CONTROL UNIT, SMART POWER | 001 |
| 5 | 38330-T5A-J01 | BOX ASSY., SUB RELAY | 001 |
| 6 | 38387-TZ5-A01 | ANTENNA ASSY., LF | 001 |
| 7 | 38387-TZ5-A01 | ANTENNA ASSY., LF | 002 |
| 9 | 38388-T9A-Z00 | BRACKET, LF ANTENNA | 001 |
| 10 | 72147-T9A-H04 | FOB ASSY., ENTRY KEY | 002 |
| 11 | 72148-SNB-000 | BATTERY COMP. (CR2032) | 002 |
| 12 | 74940-TZ5-A01 | BUZZER ASSY., SMART | 001 |
| 13 | 90361-SV4-003 | NUT, PAINT CUTTING, 6MM | 002 |
| 14 | 90701-T2A-003 | BOLT, FLANGE, 6X12 (SELF LOCK) | 002 |
| 16 | 91534-SHJ-003 | CLIP, COUPLER (DARK GRAY) (SEAL) | 001 |
| 18 | 93913-25420 | SCREW, TAPPING, 5X16 | 002 |
| 19 | 94050-06080 | NUT, FLANGE, 6MM | 002 |
| 20 | 94071-06080 | NUT-WASHER, 6MM | 001 |
