Description
B-17-21 HEATER UNIT (RH) (’21-)
| Ref No. | Parts No. | Parts Name | Unit Qty |
|---|---|---|---|
| 1 | 79101-3S6-K01 | DUCT A | 001 |
| 2 | 79102-3S6-K01 | DUCT B | 001 |
| 3 | 79106-3S6-K41 | HEATER SUB ASSY. | 001 |
| 4 | 79107-3S6-K01 | CASE SET, HEATER LOWER | 001 |
| 5 | 79108-T5R-A01 | CLAMP, HEATER PIPE | 001 |
| 6 | 79108-T9D-K01 | PLATE | 001 |
| 7 | 79109-T9D-K01 | CASE D, HEATER | 001 |
| 8 | 79110-T9D-K01 | CORE COMP., HEATER | 001 |
| 9 | 79140-T9D-K41 | MOTOR ASSY., MODE | 001 |
| 10 | 79160-T9D-K41 | MOTOR ASSY., AIR MIX | 001 |
| 11 | 79731-T5R-A01 | GROMMET, HEATER PIPE | 001 |
| 12 | 79800-T9D-K41 | JOINT ASSY., DUCT | 001 |
| 13 | 80210-T5S-F01 | EVAPORATOR SUB ASSY. | 001 |
| 14 | 80220-T5R-A01 | VALVE ASSY., EXPANSION | 001 |
| 15 | 80271-T9A-T00 | HOSE, DRAIN | 001 |
| 16 | 80534-SAA-941 | ASPIRATOR | 001 |
| 17 | 80560-TG1-T01 | THERMISTOR SUB ASSY. | 001 |
| 18 | 80566-SNK-A01 | CLIP, EVAPORATOR SENSOR | 001 |
| 19 | 80871-SN7-003 | O-RING (5/8″) | 001 |
| 20 | 80872-SN7-003 | O-RING (1/2″) | 001 |
| 21 | 90126-S5J-M01 | BOLT, SOCKET, 5X40 | 002 |
| 22 | 90127-S3N-003 | SCREW, TAPPING, 4X16 | 005 |
| 24 | 90321-SV4-003 | NUT-WASHER, 6MM (PAINT CUTTING) | 002 |
| 25 | 91580-SM4-003 | CLIP, COUPLER (ORANGE) | 001 |
| 26 | 93913-14420 | SCREW, TAPPING, 4X16 (PO) | N |
| 27 | 94071-08080 | NUT-WASHER, 8MM | 001 |
