Description
B-33-10 P.S. GEAR BOX (EPS) (RH)
| Ref No. | Parts No. | Parts Name | Parts Name(S/M) | Unit Qty |
|---|---|---|---|---|
| 1 | 06535-T4R-305 | BOOT SET, TIE ROD END | 002 | |
| 2 | 53106-S0A-003 | O-RING, 54.4X3.1 | 001 | |
| 3 | 53429-T20-A02 | SEAL SET, DUST | Boot | 002 |
| 4 | 53434-S84-A01 | CLIP, STEERING TIE ROD | Tie-Rod Clip | 002 |
| 5 | 53449-S5A-003 | BAND, BELLOWS | Boot Band | 002 |
| 6 | 53470-T24-T00 | STIFFENER, R. GEAR BOX MOUNTING | Steering Gearbox Right Stiffener | 001 |
| 7 | 53480-T24-T00 | STIFFENER, L. GEAR BOX MOUNTING | Steering Gearbox Left Stiffener | 001 |
| 8 | 53502-T24-T00 | GROMMET, STEERING | Pinion Shaft Grommet | 001 |
| 9 | 53521-TBA-A01 | END COMP., RACK | Rack End | 002 |
| 9 | 53521-TEA-A51 | END COMP., RACK | Rack End | 002 |
| 10 | 53537-TBA-A01 | RUBBER, STOPPER | 002 | |
| 11 | 53540-T20-A02 | END COMP., R. TIE ROD | Tie-Rod End | 001 |
| 12 | 53560-T20-A02 | END COMP., L. TIE ROD | Tie-Rod End Ball Joint Boot | 001 |
| 13 | 53630-T24-B04 | BOX ASSY., POWER STEERING GEAR (EPS) (REWRITABLE) | Steering Gearbox/Steering Gearbox/Steering Gearbox/Steering Gearbox/Steering Gearbox/Steering Gearbox | 001 |
| 14 | 53660-T24-B03 | MOTOR COMP. (EPS) (SERVICE) (REWRITABLE) | EPS Motor/Control Unit/EPS Motor/Control Unit/EPS Motor/Control Unit/EPS Motor/Control Unit/EPS Motor/Control Unit/EPS Motor/Control Unit | 001 |
| 15 | 53692-T24-T10 | PLATE, POWER STEERING HEAT BAFFLE (RH) | Power Steering Heat Baffle Plate | 001 |
| 16 | 53792-T21-A01 | BUSH, MOTOR | Motor Bush | 001 |
| 17 | 90102-TR0-A01 | BOLT, FLANGE, 8X30 | 002 | |
| 18 | 90108-T20-A00 | BOLT, FLANGE, 14X80 | 003 | |
| 19 | 90159-TBA-A00 | BOLT-WASHER, 10X25 | 003 | |
| 20 | 90505-T20-A00 | WASHER, PLAIN, 14MM | Washer | 002 |
| 21 | 91411-S84-A01 | NUT, HEX., 14MM | 002 | |
| 22 | 91535-STK-003 | CLIP, COUPLER (DARK BLUE) | 001 | |
| 23 | 93404-06012-05 | BOLT-WASHER, 6X12 | 003 | |
| 24 | 94030-12280 | NUT, HEX., 12MM | 002 | |
| 25 | 94201-30220 | PIN, SPLIT, 3.0X22 | 002 |
