EGR Valve

18011-5R0-000 EGR Valve

EGR Valve

Category:

Description

18011-5R0-000 EGR Valve

E-10-10 EGR VALVE

Ref No. Parts No. Parts Name Parts Name(S/M) Unit Qty
1 12210-PZ1-004 SEAL A, VALVE STEM (NOK) Intake Valve Seal/Intake Valve Seal 008
2 12211-PZ1-004 SEAL B, VALVE STEM (NOK) Exhaust Valve Seal/Exhaust Valve Seal 008
3 12251-5R0-J01 GASKET COMP., CYLINDER HEAD (NOK) 001
4 12511-5P6-000 PLATE, CYLINDER HEAD IN. Cylinder Head Intake Plate 001
5 12512-5R0-J50 PLATE, CYLINDER HEAD EX. Cylinder Head Exhaust Plate 001
6 12513-5R0-000 COVER, CAMSHAFT HOLDER Cam Holder Cover 001
7 15830-5R1-J02 VALVE ASSY., VTC OIL CONTROL 001
8 15832-PNA-023 O-RING 001
9 18011-5R0-000 VALVE SET, EGR 001
10 18714-5R1-010 STAY, EGR PASSAGE 001
11 18715-PB2-000 GASKET, EGR VALVE (ISHINO GASKET) 001
12 18718-5R1-J50 PASSAGE COMP., EGR VALVE EGR Passage 001
13 18723-5R0-J01 GASKET, EGR PASSAGE 001
14 37510-59B-J01 SENSOR ASSY., TDC Camshaft Position (CMP) Sensor A/Camshaft Position (CMP) Sensor B 001
15 90008-PWA-003 BOLT-WASHER, 9X155 010
16 90025-5R0-000 BOLT, STUD, 8X32 002
17 90026-5R0-000 BOLT, STUD, 8X50 002
18 90026-RMX-000 BOLT, STUD, 8X22 002
19 91301-5R0-003 O-RING A, HEAD PLATE 002
20 91303-5R1-003 O-RING B, HEAD PLATE 001
21 91333-PNA-003 O-RING, 15X1.9 001
22 92900-08022-1B BOLT, STUD, 8X22 002
23 92900-08080-0B BOLT, STUD, 8X80 002
24 94050-06080 NUT, FLANGE, 6MM 001
25 94050-08080 NUT, FLANGE, 8MM 004
26 94301-14200 DOWEL PIN, 14X20 002
27 95701-06014-08 BOLT, FLANGE, 6X14 001
28 95701-06016-08 BOLT, FLANGE, 6X16 001
29 95701-06020-08 BOLT, FLANGE, 6X20 001
30 95701-08016-08 BOLT, FLANGE, 8X16 002
31 95701-08030-08 BOLT, FLANGE, 8X30 002
32 95701-08055-08 BOLT, FLANGE, 8X55 001
33 95701-08070-08 BOLT, FLANGE, 8X70 002
34 95701-08080-08 BOLT, FLANGE, 8X80 001
35 90028-PNB-003 BOLT, SPECIAL, 6X20.5 (GUIDE) 001
