Description
B-46 FRONT BUMPER (-’24)
| Ref No. | Parts No. | Parts Name | Parts Name(S/M) | Unit Qty |
|---|---|---|---|---|
| 1 | 04711-T29-T00ZZ | FACE, FR. BUMPER | 001 | |
| 2 | 71104-T20-A00 | LID, MAINTENANCE | Maintenance Lid | 002 |
| 3 | 71105-T20-A00 | SPOILER, FR. BUMPER AIR | Front Bumper Air Spoiler | 001 |
| 4 | 71130-T24-T00 | BEAM COMP., FR. BUMPER | 001 | |
| 5 | 71141-T39-A10 | GARNISH, R. FR. FOG LIGHT | Front Bumper Side Trim/Front Bumper Side Trim | 001 |
| 7 | 71145-S21-000 | BASE, FR. LICENSE PLATE | 001 | |
| 8 | 71151-T24-T00 | GRILLE, FR. BUMPER LOWER | Front Bumper Lower Grille | 001 |
| 9 | 71170-T24-T00 | PLATE ASSY., FR. BUMPER SAFETY | Front Bumper Safety Plate | 001 |
| 10 | 71175-T24-T00 | PLATE, FR. BUMPER LOWER SAFETY | Front Lower Plate | 001 |
| 11 | 71176-T20-A00 | SUPPORT, SAFETY PLATE | Front Lower Plate Support | 002 |
| 12 | 71180-T24-T00 | BASE, FR. LICENSE PLATE | 001 | |
| 13 | 71191-T39-A10 | GARNISH, L. FR. FOG LIGHT | Front Bumper Side Trim/Front Bumper Side Trim | 001 |
| 14 | 71230-T24-T01 | SPACER, R. FR. BUMPER SIDE | Front Bumper Side Spacer | 001 |
| 15 | 71240-T20-A00 | BEAM, R. FR. BUMPER CORNER UPPER | Front Bumper Corner Upper Trim | 001 |
| 16 | 71280-T24-T01 | SPACER, L. FR. BUMPER SIDE | Front Bumper Side Spacer | 001 |
| 17 | 71290-T20-A00 | BEAM, L. FR. BUMPER CORNER UPPER | Front Bumper Corner Upper Trim | 001 |
| 18 | 71321-T20-A10 | PLATE, FR. BUMPER UPPER INDUCTION | Front Bulkhead Air Shroud/Front Bulkhead Air Shroud | 001 |
| 19 | 71325-T20-A00 | PLATE, R. FR. BUMPER SIDE DUCT | Front Bumper Lower Grille Cover | 001 |
| 20 | 71336-T24-T00 | PLATE, R. FR. BUMPER MIDDLE INDUCTION | Front Bumper Air Screen | 001 |
| 21 | 71375-T20-A00 | PLATE, L. FR. BUMPER SIDE DUCT | Front Bumper Lower Grille Cover | 001 |
| 22 | 71386-T24-T00 | PLATE, L. FR. BUMPER MIDDLE INDUCTION | Front Bumper Air Screen | 001 |
| 23 | 71416-T20-A00 | STAY, R. FR. BULKHEAD LOWER | 001 | |
| 24 | 71466-T20-A00 | STAY, L. FR. BULKHEAD LOWER | 001 | |
| 25 | 90102-SAA-901 | BOLT, SPECIAL, 6MM | 004 | |
| 26 | 90102-TBA-A00 | BOLT-WASHER, 10X36 | 008 | |
| 27 | 90113-SJA-A00 | SCREW, TAPPING, 5X14 | 006 | |
| 28 | 90144-SA0-020 | BOLT, BUMPER SETTING (6X15) (BLACK) | 008 | |
| 29 | 90144-TA9-000 | BOLT, BUMPER | 002 | |
| 30 | 90149-SA0-003 | BOLT, BUMPER | 002 | |
| 31 | 90305-SM4-000 | NUT, AIR SPOILER CLIP | 002 | |
| 32 | 90675-SA5-003 | NUT, CLIP, 6MM | 002 | |
| 33 | 91505-TM8-003 | CLIP, BUMPER | 037 | |
| 34 | 93401-06020-08 | BOLT-WASHER, 6X20 | 002 | |
| 35 | 93404-06016-05 | BOLT-WASHER, 6X16 | 006 | |
| 36 | 93404-06020-05 | BOLT-WASHER, 6X20 | 004 | |
| 37 | 93405-06020-05 | BOLT-WASHER, 6X20 | 002 | |
| 38 | 93405-08025-05 | BOLT-WASHER, 8X25 | 004 | |
| 39 | 93903-25320 | SCREW, TAPPING, 5X16 | 002 | |
| 40 | 93903-45480 | SCREW, TAPPING, 5X20 | 002 |
