Description
B-17-20 HEATER UNIT (RH)
| Ref No. | Parts No. | Parts Name | Parts Name(S/M) | Unit Qty |
|---|---|---|---|---|
| 1 | 79101-T24-T61 | DUCT ASSY., HEATER (DRIVER SIDE) | Driver’s Heater Duct A | 001 |
| 2 | 79102-T24-T00 | DUCT ASSY., HEATER (DRIVER SIDE) | Driver’s Heater Duct B | 001 |
| 3 | 79103-T24-T61 | DUCT ASSY., HEATER (PASSENGER SIDE) | Passenger’s Heater Duct | 001 |
| 4 | 79105-T24-T00 | STAY, HVAC | HVAC Stay | 001 |
| 5 | 79106-T24-Q81 | HEATER SUB ASSY. | Heater Unit | 001 |
| 6 | 79108-T24-A41 | CASE SET, EVAPORATOR | Evaporator Case | 001 |
| 7 | 79110-T24-T41 | CORE COMP., HEATER | Heater Core | 001 |
| 8 | 79111-TZA-J01 | STAY, HEATER PIPE | 001 | |
| 9 | 79121-TG1-T01 | SCREW-WASHER, 6X20 | 001 | |
| 10 | 79140-T02-T01 | MOTOR ASSY., MODE (R.) | Mode Control Motor | 002 |
| 11 | 79150-TAA-J41 | MOTOR ASSY., TEMPERATURE DRIVER | Driver’s Air Mix Control Motor / Air Mix Control Motor / Passenger’s Air Mix Control Motor | 001 |
| 12 | 79150-TLA-A51 | MOTOR ASSY., TEMPERATURE (L.) | Driver’s Air Mix Control Motor / Air Mix Control Motor / Passenger’s Air Mix Control Motor | 001 |
| 13 | 79308-T24-A41 | JOINT SET, DUCT | Joint Duct | 001 |
| 14 | 79330-TZ3-A01 | TRANSISTOR ASSY. | Power Transistor | 001 |
| 15 | 79731-S5A-000 | GROMMET, HEATER PIPE | 001 | |
| 16 | 80210-TAA-J41 | EVAPORATOR SUB ASSY. | Evaporator Core | 001 |
| 17 | 80220-T24-K31 | VALVE ASSY., EXPANSION | Expansion Valve | 001 |
| 18 | 80271-T24-T00 | HOSE, DRAIN | Drain Hose | 001 |
| 19 | 80534-SAA-941 | ASPIRATOR | Aspirator | 001 |
| 20 | 80560-TAA-J41 | THERMISTOR, AIR CONDITIONER | Evaporator Temperature Sensor | 001 |
| 21 | 80566-TG1-T01 | CLIP, EVAPORATOR SENSOR | 001 | |
| 22 | 80650-T24-B51 | SUB HARNESS, AIR CONDITIONER | A/C WIRE HARNESS/A/C WIRE HARNESS | 001 |
| 23 | 80871-SN7-003 | O-RING (5/8″) | 001 | |
| 24 | 80872-SN7-003 | O-RING (1/2″) | 001 | |
| 25 | 90126-S5J-M01 | BOLT, SOCKET, 5X40 | 002 | |
| 26 | 90127-S3N-003 | SCREW, TAPPING, 4X16 | 010 | |
| 27 | 90127-SX0-003 | SCREW, TAPPING, 4X16 | N | |
| 28 | 90321-TAA-000 | NUT-WASHER, 6MM (PAINT CUTTING) | 002 | |
| 29 | 91501-TR0-003 | CLIP, INNER FENDER | 001 | |
| 30 | 91534-SWA-003 | CLIP, COUPLER (DARK GRAY) | 001 | |
| 31 | 91540-TA0-003 | CLIP, HARNESS BAND (NATURAL) (100.1MM) | 003 | |
| 32 | 91549-TA0-003 | CLIP, HARNESS BAND (BLACK) (140.3MM) | 003 | |
| 33 | 91580-SM4-003 | CLIP, COUPLER (ORANGE) | 001 | |
| 34 | 94071-08080 | NUT-WASHER, 8MM | 001 | |
| 35 | 95701-06012-08 | BOLT, FLANGE, 6X12 | 001 | |
| 36 | 39248-692-003 | PACKING, HEATER | 001 |
