Description
E-10-10 SPOOL VALVE
| Ref No. | Parts No. | Parts Name | Parts Name(S/M) | Unit Qty |
|---|---|---|---|---|
| 1 | 12208-PWA-003 | BOLT, SEALING, 16MM | 001 | |
| 2 | 12209-PWA-000 | WASHER, SEALING, 16MM | 001 | |
| 3 | 12210-PZ1-004 | SEAL A, VALVE STEM (NOK) | 008 | |
| 4 | 12211-PZ1-004 | SEAL B, VALVE STEM (NOK) | 008 | |
| 5 | 12230-RB0-000 | COVER, CAM THRUST | 001 | |
| 6 | 12251-RB0-004 | GASKET COMP., CYLINDER HEAD (NIPPON LEAKLESS) | 001 | |
| 7 | 15810-RB0-003 | VALVE ASSY., SPOOL | 001 | |
| 8 | 15825-RB0-003 | FILTER ASSY., SPOOL VALVE | 001 | |
| 9 | 37510-RB0-003 | SENSOR ASSY., TDC | 001 | |
| 11 | 90008-PWA-003 | BOLT-WASHER, 9X155 | 010 | |
| 12 | 91302-RE2-E01 | O-RING, 46.8X2.2 (ARAI) | 001 | |
| 14 | 91333-PNA-003 | O-RING, 15X1.9 | 001 | |
| 15 | 92900-08022-0E | BOLT, STUD, 8X22 | 002 | |
| 16 | 92900-08055-0B | BOLT, STUD, 8X55 | 002 | |
| 17 | 94301-14200 | DOWEL PIN, 14X20 | 002 | |
| 18 | 95701-06016-08 | BOLT, FLANGE, 6X16 | 001 | |
| 19 | 95701-06020-08 | BOLT, FLANGE, 6X20 | 002 | |
| 20 | 95701-06045-08 | BOLT, FLANGE, 6X45 | 003 |
